Rhythm mapped by

BeatScope

Every stroke lands on a measured beat.

BeatScope turns a song into a beat-synchronised film — or gives its timing to a coding agent. Runs locally. MIT.

Download for Windows View on GitHub →

Shattered Heartbeat

A film by chornic · 2026

73.5 s · 132.5 BPM · 161 beats · 751 onsets

Room I

The Collection

Sixteen paintings, repainted on the beat. No AI images — every stroke is procedural, every cut is measured.

The Great Wave off Kanagawa, repainted as a woodblock print in the film — The Great Wave off Kanagawa

Katsushika Hokusai · 1831

Woodblock · Beat 34 · Bar 9

Fine Wind, Clear Morning (Red Fuji), repainted as a woodblock print — Fine Wind, Clear Morning

Katsushika Hokusai · 1831

Woodblock · Beat 42 · Bar 11

The Scream, repainted in impasto oil strokes — The Scream

Edvard Munch · 1893

Impasto oil · Beat 24 · Bar 6

Starry Night Over the Rhône, repainted in impasto oil strokes — Starry Night Over the Rhône

Vincent van Gogh · 1888

Impasto oil · Beat 56 · Bar 14

Girl with a Pearl Earring, repainted in watercolour washes — Girl with a Pearl Earring

Johannes Vermeer · 1665

Watercolour · Beat 73 · Bar 19

Takiyasha the Witch and the Skeleton Spectre, repainted in sumi ink washes — Takiyasha the Witch and the Skeleton Spectre

Utagawa Kuniyoshi · 1844

Sumi ink · Beat 90 · Bar 23

Room II

How the film was made

Drop in a song.

Step I · WAV FLAC MP3 OGG M4A

Analysed on your machine. Your audio is never uploaded.

Every hit, mapped.

Step II · Beats · Bars · Onsets · Low/Mid/High

Review the rhythm map, song structure and film preview; edit stage boundaries and cue markers.

A film that hears it.

Step III · 1080×1080 · 30 FPS MP4

Render the full song with Voxel Interference or Prismatic Echo.

Hand the timing to your agent.

Step IV · .beatscope package · MIDI · CSV

Export the package and give it to a coding agent with your own media.

Shattered Heartbeat itself was built this way: BeatScope measured the track, a coding agent painted to the timing.

Room III

Two ways out

Exhibit AFilm

A film you can watch

Two templates: Voxel Interference (procedural glitch visuals) and Prismatic Echo (grey, blue and red footage, mirrors, kaleidoscopes, contour trails and sparse moving negatives).

Both render the full song to MP4 at 1080×1080, 30 fps; live preview at 540×540.

Edit stage boundaries and add, move or mute cue markers on the rhythm graph, with undo/redo and optional snapping.

Prismatic Echo uses GPU composition, hardware encoding and reusable caches; devices without the required GPU fall back to a Canvas renderer.

Template guide →

Exhibit BAgent

Timing a coding agent can use

Export the .beatscope package and give it to an agent with your footage, images or references. It holds measured timing, not a fixed visual style.

Flow

Your song
BeatScope measures the timing
.beatscope package + your media + your idea
Coding agent creates the visual

In the package

rhythm-map.json
MIDI and CSV views
A deterministic JavaScript runtime
A self-checking probe
Member hashes
Short agent instructions
A reference comparison helper

It does not include your audio or a visual template.

Agent handoff guide →

Object list

What BeatScope measures

Whole-song structure and eight-bar rhythm detail
Beats, bars and tempo changes
Original onset timestampsThe sound is never moved onto a prettier grid.
LOW / MID / HIGH spectral activity
Neutral repeated sections (A / B / A′)
Response ordering for dense songsOptional.

“BeatScope does not pretend to know whether a sound is a kick, snare or 808. It reports evidence and lets the renderer decide.”

Plan your visit

Visitor information

Admission

Free.

Open source, MIT licensed.

Windows

Download Beathi Studio v0.15.0, extract the whole ZIP, double-click Beathi Studio.exe.

Includes the analyser, Node.js, Playwright, FFmpeg and the material pack. Rendering uses Microsoft Edge on Windows 10/11.

Download for Windows

Python 3.10+

Download the wheel from the v0.15.0 release, then run:

pip install beatscope-0.15.0-py3-none-any.whl
beatscope serve --open

For Prismatic Echo, extract the material pack into your working directory (keep its materials/ folder) or set BEATSCOPE_MATERIAL_ROOT.

Python rendering also needs Node.js, FFmpeg, Playwright and a supported browser.

Local rendering →

For developers

MCP server

A local stdio MCP server for analysis and bounded timing queries.

WebMCP tools

Seven browser WebMCP tools inside Beathi Studio.

Code

git clone https://github.com/chosuicide/beatscope.git
cd beatscope
python -m venv .venv
.\.venv\Scripts\Activate.ps1
pip install -e ".[dev,mcp]"
beatscope serve --open

Contributions welcome — new visual templates and timing consumers are a great place to start.

GitHub issues →
